| Standartlar ve Protokoller | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af,
IEEE 802.3x, IEEE 802.1q, IEEE 802.1p |
|---|
| Arabirim | 8 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX |
|---|
| Ağ Medyası | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m) |
|---|
| Fan Sayısı | Fanless |
|---|
| Güç Kaynağı | External Power Adapter(Output: 48VDC / 1.25A) |
|---|
| Güç Tüketimi | Maximum (PoE on): 65.2W (220V/50Hz)
Maximum (PoE off): 5.2W (220V/50Hz) |
|---|
| PoE+ Portları (RJ45) | Standard: 802.3 af compliant
PoE Ports: Port 1- Port 4
PoE Power Budget: 55W |
|---|
| PoE Portları (RJ45) | Standard: 802.3 af compliant
PoE Ports: Port 1- Port 4
PoE Power Budget: 55W
|
|---|
