Camera |
Image Sensor | 1/2.8 inch CMOS |
Effective Pixels | 1920 (H) × 1080 (V), 2MP |
Scanning System | Progressive |
Electronic Shutter Speed | PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s |
S/N Ratio | > 65dB |
Minimum Illumination | 0.01Lux/F1.6, 0Lux white light on |
Illumination Distance | Distance up to 20 m (65.61 ft) |
Illuminator On/Off Control | Auto; manual |
Illuminator Number | 1 |
Pan/Tilt/Rotation Range | Pan: 0°–360°
Tilt: 0°–180°
Rotation: 0°–360° |
Lens |
Lens Type | Fixed-focal |
Mount Type | M12 |
Focal Length | 2.8 mm ;3.6 mm |
Max. Aperture | F1.6 ;F1.6 |
Field of View | 2.8 mm: 126.2° × 106° × 56.5° (diagonal × horizontal × vertical);
3.6 mm: 103.6° × 86.9° × 46.3° (diagonal × horizontal × vertical) |
Iris Type | Fixed iris |
Close Focus Distance | 2.8 mm: 0.6 m (1.97 ft);
3.6 mm: 1.2 m (3.94 ft) |
DORI Distance | Lens | Detect | Observe | Recognize | Identify |
2.8 mm | 38.6 m (126.6 ft) | 15.4 m (50.5 ft) | 7.7 m (26.3 ft) | 3.9 m (12.8 ft) |
3.6 mm | 55.2 m (181.1 ft) | 22.1 m (72.5 ft) | 11.0 m (36.1 ft) | 5.5 m (18.0 ft) |
Video |
Frame Rate | CVI:
PAL: 1080P@25fps; 720P@25fps;
NTSC: 1080P@30fps; 720P@30fps;
AHD:
PAL: 1080P@25fps;
NTSC: 1080P@30fps
TVI:
PAL: 1080P@25fps;
NTSC: 1080P@30fps
CVBS:
PAL: 960H;
NTSC: 960H |
Resolution | 1080P (1920 × 1080); 720P (1280 × 720); 960H (960 × 576/960 × 480) |
BLC | BLC/WDR |
WDR | DWDR |
White Balance | Auto; manual |
Gain Control | Auto; manual |
Noise Reduction | 2D NR |
Smart Light | Yes |
Mirror | Off/On |
Privacy Masking | Off/On (8 area, rectangle) |
Certifications |
Certifications | CE (EN55032, EN55024, EN50130-4,EN60950-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
Port |
Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
Audio Interface | N/A |
Power |
Power Supply | 12V ±30% DC |
Power Consumption | Max 3.0W (12V DC, White Light on) |
Environment |
Operating Temperature | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
Storage Temperature | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
Protection Grade | IP67 |
Structure |
Casing | Metal front cover + plastic main body + plastic bracket |
Camera Dimensions | 161.3 mm × 69.7 mm × 70.0 mm (6.35" × 2.75" × 2.75") |
Net Weight | 0.20 Kg (0.44 lb) |
Gross Weight | 0.28 Kg (0.62 lb) |
